OMG GYPTEC040 Polymer Internal Square Drive 4" 500ct
*This is a special order product- subject to return restrictions. Shipping and return policy
OMG GYPTEC040 Polymer Internal Square Drive 4" 500ct
The OMG Polymer GypTec is a high-strength, glass-filled nylon auger fastener with a 1-in. head designed to secure insulation and single-ply membrane to gypsum and cementitious wood fiber (i.e., Insulrock, Permadeck, Tectum, etc.). The fastener is used with 3-in. GypTec plates for insulation attachment and 2-in. GypTec plates - plates are not included - for membrane attachment: see "related products" below to order plates or other fastener sizes. Available in lengths from 2.5-in. to 12-in. (check this order's title for specific size).
OMG GYPTEC040 Polymer Internal Square Drive 4" 500ct
FEATURES & BENEFITS
- Designed for increased pullout resistance and shear strength.
- Made from glass-filled nylon, which eliminates corrosion and thermal bridging
- Non-penetrating design. Fastener threads into the deck but not through.
- Plate design locks onto the head of the GypTec fastener (plates sold separately)
TECHNICAL DATA
Thread Diameter: .675-in. (17.1 mm)
Head Diameter: 1-in. (25.4 mm)
Material: Glass-filled nylon
Plate Material: Galvalume coated steel
PRODUCT USE
The OMG Polymer GypTec is Factury Mutual approved for insulation attachment only. See system manufacturer for membrane attachment requirements.
Installation at a low RPM is recommended. Minimum fastener embedment into the deck should be 1 1/2 in. (2 in. recommended). The Polymer GypTec fastener should never penetrate the underside of the deck.
OMG Polymer GypTec fasteners can be installed into some cementitious wood fiber decks without pre-drilling. A pilot hole is required for gypsum. Use a 7/16-, 1/2- or 9/16-in. drill bit as determined by pullout test results. Pilot holes must be a minimum of 1/2-in. deeper than embedment. Polymer GypTec fasteners should be installed using a heavy duty variable speed screw gun.
| Stock Info | Out of Stock |
|---|---|
| Manufacturer | OMG |
