Please click the pdf attachment below to review detailed information about recommended or required installation steps and materials including:

• Safe Temperature Installation Range
• Substrate
• Underlayment
• Fasteners
• Flashing material
• Sealants


Specifications:

• Total Pieces= 9 pieces of 6”, 18 pieces of 9”, 9 pieces of 12” of each size (totaling 36 pieces)
• Width Varieties= 6”, 9” ,12”
• Thickness= 0.375” or 3/8”  nominal thickness
• Length= 19”
• Weight= 47 lbs per bundle
• Material= Recycled rubber and Thermoplastic Olefin (not tires)
• Origin= United States
• Operating Range= -25˚F to 200˚F (-32˚C to 93˚C)
• Tensile (D-412)= 1,500 psi (10,342 kpa)
• Water Absorption (D-570)= 0% by wt
• UL Listed 790 Fire Resistance= Class C
• UL 2218 Impact= Class 4


Slope:

The tiles are not recommended for slopes less than 3/12 (14˚). If this is desired, contact the technical department for review. On roof slopes less than 6/12 (27˚), the tiles must be installed with a maximum 7” (178 mm) exposure. On roof slopes of 6/12 (27˚) or greater, the tiles may be installed with a 7” (178 mm) or 8” (203 mm) exposure.

Warranty Type: 2 options available

• 50-Year Limited Material Warranty available
• 50-Year Gold Star Labor & Material Warranty available

The warranty will be honored only through the manufacturer, EcoStar. For your convenience, product warranty information is attached below; please click the link to view the current warranty policy on the manufacturer's site. If you need further assistance regarding your coverage or have other inquiries, please contact the manufacturer directly.

Link:  EcoStar Warranty Information
